Wooden Bell Turret [Building News Designing Club]
Collection:CSM Museum & Study Collection
Date: 1877
Maker: William Richard Lethaby (1857-1931)
Dimensions:
Image: 85 x 125 mm (8.5 x 12.5 cm)
Sheet: 327 x 215 mm (32.7 x 21.5 cm)
Medium: Black printing ink on paper
Object number: R.85.2
DescriptionA design for a "Wooden Bell Turret to a Country Church Height 10 feet to apex from ridge of roof". Reproduced in the Building News, issue dated March 2nd 1877. Shows 1) front elevation (from west end of church) 2) side elevation 3) plan 4) section 5) sketch 6) detail. Labelled with various notes. A scale in feet and inches. Reduced from original size. See F.1.1993.6
