Wooden Bell Turret [Architectural drawing]
Collection:CSM Museum & Study Collection
Date: 1877
Maker: William Richard Lethaby (1857-1931)
Dimensions:
Image: 451 x 293 mm (45.1 x 29.3 cm)
Sheet: 486 x 319 mm (48.6 x 31.9 cm)
Medium: Ink and pencil on paper (Whatman hand made wove)
Object number: F.1.1993.6
DescriptionFull title "Wooden Bell Turret to a Country Church. Height 10 feet to apex from ridge of roof". Shows 1) Front elevation 2) side elevation 3) section 4) sketch 5) plan and 6) detail. Signed with the Debut pseudonym, and a scale in feet and inches.
