Foliated Hinges for a Church in wrought iron [Architectural drawings]
Collection:CSM Museum & Study Collection
Date: 1877
Maker: William Richard Lethaby (1857-1931)
Dimensions:
335 x 470 mm (33.5 x 47 cm)
Image: 306 x 430 mm (30.6 x 43 cm)
Sheet: 334 x 470 mm (33.4 x 47 cm)
Medium: Pencil, pen and ink on wove paper (probably Whatman hand made).
Object number: F.5
Descriptionarchitectural design showing door with elaborate iron metalwork scroll and foliated hinges: 1) upper hinge 2) lower hinge 3) an elevation of the door detailing the position of the hinges and a scale in feet and inches. Signed with the Debut pseudonym.
There is evidence of a different drawing, erased, on the right hand side of the recto.
