[Architectural sketch: Cross-section of a roof]
Collection:CSM Museum & Study Collection
Date: 1870s - 1920s
Maker: William Richard Lethaby (1857-1931)
Dimensions:
Image: 333 x 199 mm (33.3 x 19.9 cm)
Sheet: 333 x 207 mm (33.3 x 20.7 cm)
Medium: Pencil on laid paper
Object number: F.145.3
DescriptionA sketch by Lethaby of the cross-section of a roof detailing the tiles, the guttering etc. and giving the details of the dimensions and specifications.
